WG211 Wifi Module for Gaming Consoles is a highly integrated Wi-Fi single chip that supports a 433Mbps PHY rate.
Read More| Chip | MT7610U |
| Voltage | :3.5-5.5V |
| Dimensions | 36mm*15mm |
WG211 Wifi Module for Gaming Consoles is a highly integrated Wi-Fi single chip that supports a 433Mbps PHY rate. It is compliant with IEEE 802.11ac draft specification, offering feature-rich wireless connectivity and reliable throughput from an extended distance.
WG211 is designed to support standard-based features in the areas of security, quality of service, and international regulations, giving end-users the greatest performance any time and in any circumstance.
◆IEEE 802.11a/b/g/n/ac WLANs
◆2.4/5G ITIR mode
◆With the support of 433Mbps PHY rate
◆Compliant IEEE802.11d and 802.11h
◆Complies with USB2.1 specifications
◆Fully compliant with USB2.0 High-speed mode.
◆Security: WEP 64/128, WPA, WPA2, TKIP, AES, WAPI.
◆Supports for Windows XP 32/64, 2000, Vista 32/64bit, Windows 7 32/64bit, Linux, Android.
◆RoHS compliance meets the environment-friendly requirements.
◆FCC, CE compliance.
◆36.0(L) x 15.0(W) x 3.2mm small dimension.
| Hardware Features | ||||
| Model | WG211 | |||
| Antenna Type | IPEX connecter or PCB antenna | |||
| Chipset Solution | MT7610U | |||
| Voltage | 3.5-5.5V | |||
| Dimensions (W×D) | 36mm*15mm | |||
| Wireless Standards | IEEE 802.11 a/b/g/n/ac | |||
| Frequency Range | 2.4/5GHz | |||
| Data Rates | IEEE 802.11a Standard Mode: 6, 9, 12, 18, 24, 36, 48, 54Mbps | |||
| IEEE 802.11 b Standard Mode: 1, 2, 5.5, 11Mbps | ||||
| IEEE 802.11g Standard Mode: 6, 9, 12, 18, 24, 36, 48, 54Mbps | ||||
| IEEE 802.11n/Draft 2.0 Mode: 130Mbps @ HT20 | ||||
| 150Mbps @ HT40 IEEE 802.11ac Standard Mode: 460Mbps @VHT80 | ||||
| 2.4G Receive Sensitivity | HT40 MCS15: -72dBm@10% PER(MCS7) | |||
| HT20 MCS15 : -75dBm@10% PER(MCS7) | ||||
| 54M: -77dBm@10% PER | ||||
| 11M: -90dBm@ 8% PER | ||||
| 5G Receive Sensitivity | VHT80 MCS15: -62dBm@10% PER(MCS9) | |||
| HT40 MCS15: -71dBm@10% PER(MCS7) | ||||
| OFDM 54M: -75dBm@10% PER | ||||
| OFDM 6M: -90dBm@ 8% PER | ||||
| Modulation Technology | 802.11 Legacy b/g/n | |||
| DSSS (DBPSK, DQPSK, CCK) | ||||
| OFDM (BPSK, QPSK, 16-QAM, 64-QAM) | ||||
| 802.11ac | ||||
| OFDM (256-QAM) | ||||
| Wireless Security | Supports WEP64/128, WPA, WPA2, TKIP, WAPI, and AES hardware encryption | |||
| Wireless Transmit Power | IEEE 802.11ac: 9-11dBm @HT80 MCS7 | |||
| IEEE 802.11n: 12-15dBm @HT40 MCS7 | ||||
| With ±2dBm Tolerance | 12-15dBm@HT20 MCS7 | |||
| IEEE 802.11g: 15dBm | ||||
| IEEE 802.11b: 17dBm | ||||
| Work Mode | AP/Ad-Hoc / Infrastructure mode | |||
| Others | ||||
| Certification | RoHS, FCC, CE | |||
| Power Consumption@25°C | Status | POWER | 2.4G/mA | 5G/mA |
| Transmission HT40/MCS 15 | 5.0V | 150 | 160 | |
| Receiving HT40/MC 15 | 5.0V | 90 | 90 | |
| Environment | Operating Temperature: -10℃~70℃ (14℉~158℉) | |||
| Storage Temperature: -40℃~125℃ (-40℉~257℉) | ||||
| Operating Humidity: 10%~90% non-condensing | ||||
| Storage Humidity: 5%~90% non-condensing | ||||
◆IP Camera
◆IP TV
◆ IP DVD(Internet VOD Player)
◆ Set Top Box
◆Gaming Consoles
◆DVR
