Large commercial supermarkets, airports and railway stations have basically achieved wireless network coverage. At present, the application field of router WiFi modules has gradually extended from indoor to outdoor environments.
The WiFi module supports AP/Client, Bridge, Gateway, Router, 3G/4G Router and other modes. The wireless router WiFi modules developed by SKYLAB include SKW77, SKW92A, SKW92B, SKW95, SKW99, SKW97, SKW78, SKW93A, SKW100, etc. SKYLAB router WiFi module has the characteristics of stable performance and high cost performance.
In this article, I recommend four of the best-selling router WiFi modules in 2023.
SKW92A is a WiFi module based on MT7628N chip. In 20MHz bandwidth it can reach 144Mbps data transmission speed. In 40MHZ bandwidth it can reach 300Mbps data transmission speed. The SKW92AWiFi module supports 5 working modes, including bridge, AP Client, and gateway modes.
Its high performance can handle a variety of advanced applications, such as: routers, security and VoIP. SKW92A has a variety of interfaces and supports various applications, especially in the IOT field.
SKW99 is a WiFi module based on QCA9531 chip. It is a dual-antenna design and supports up to 300Mbps PHY data transmission rate in 2T2R mode. SKW99 adopts industrial-grade design, which has the characteristics of low power consumption and low heat generation.
It supports LAN port and WAN port, and supports more 3G/4G module models. SKW99 supports UART WiFi transparent transmission. SKW99 WiFi module supports bridge mode, AP client mode and gateway mode.
SKW93A is a dual-frequency AP routing WiFi module based on MT7628+MT7603E chips. SKW93A can work in 2.4GHz and 5GHz dual frequency at the same time. 3x3 MIMO, respectively 2x2 MIMO 2.4GHz, 1x1 MIMO 5GHz.
It is in the 2.4G frequency band, and the transmission speed can reach 300Mbps. It is in the 5GHz frequency band, and the transmission speed can reach 433Mbps. It has 2 serial ports, USB, IIS, IIC, SD; with 1 WAN, 2 LANs.
SKW100 is based on QCA9531+QCA9887 dual-band AP routing WiFi module. It can work on both 2.4GHz and 5GHz dual frequency at the same time. SKW100 has built-in PA and LNA, 3x3 MIMO, respectively 2x2 MIMO 2.4GHz, 1x1 MIMO 5GHz.
SKW100 has a built-in 650MHz dual core, and for consumer electronic devices, the module only needs an external 3.3V power supply.
SKYLAB wireless routing AP/Router WiFi modules have been supplied in batches. We are equipped with EVB boards for testing, debugging and development. If you have router WiFi module visit SKYLAB official website.
